Single Point Loadcell
Single Point Load Cell(50~500kg)
The SPCK500 series single point load cell is designed for platform scale, hopper scale and automatic check weighing systems where great accuracy, reliability and fast measurement are required.
SPECIFICATIONS
TYPE | SPCK500 |
Rated capacity (R.C.) | 50,100,200,300,500kg |
Rated output(R.O.) | 2mV/V ± 10% |
Non-linearity | ≤0.02% R.O. |
Hysteresis | ≤0.02% R.O. |
Non-repeatability | ≤0.02% R.O. |
Creep error | ≤0.03% in 20min |
Zero balance | ≤5% R.O. |
Compensated temperature range | -10 ~ 70℃ |
Operating temperature range | -20 ~ 80℃ |
Temp. effect on rated output | ≤0.012% LOAD/10℃ |
Temp.effect on zero balance | ≤0.03% R.O./10℃ |
Terminal input resistance | 420 Ohms ± 10 Ohms |
Terminal output resistance | 350 Ohms ± 5 Ohms |
Insulation resistance (Min.) | 2000 MOhms at 50V DC |
Excitation voltage | 10V（Recommended）,15V（Max） |
Electrical connection | Ø5mmx3m(22AWG x 4Core Shielded) |
Protection class | meets IP 65 |
Safe overload | 150% R.C |
Ultimate overload | 300% R.C |
Capacity | Allowable Platform Size |
50~500kg (0.981~4.903N) | 700×700mm |
* Specifications are subject to change without notice
