Bending Beam Loadcell
BBCK300
Series BBCK300
Bending Beam Load Cell(10kg-300kg)
The BBCK300 series single ended bending beam load cell is designed for tension or compression loading applications including hopper scale and conveyor weighing.
-17-4PH stainless steel construction for high accuracy and corrosion resistance.
-Fully welded seal with stainless steel bellows for hostile environments and washdown applications.
SPECIFICATIONS
TYPE | BBCK300 |
Rated capacity(R.C.) | 10, 20, 50, 100, 200, 300, 500kg |
Rated output(R.O.) | 2mV/V ±3% |
Non-inearity | ≤0.03% R.O. |
Hysteresis | ≤0.02% R.O. |
Non-repeatability | ≤0.02% R.O. |
Creep error | ≤0.03% in 20min |
Zero balance | ≤1 R.O. |
Compensated temperature range | -10 ~ 70℃ |
Operating temperature range | -20 ~ 80℃ |
Temp.effect on rated output | ≤0.02% LOAD/10℃ |
Temp.effect on zero balance | ≤0.02% R.O./10℃ |
Terminal input resistance | 400 Ohms ±20 Ohms |
Terminal output resistance | 350 Ohms ±5 Ohms |
Insulation resistance (Min.) | 2000 MOhms at 50V DC |
Excitation Voltage | 10V（Recommended）,15V（Maximum） |
Electial connection | Ø5mmx3m(22AWG x 4Core Shielded) |
Protection class | Meets IP 68 |
Safe overlioad | 150% R.C |
Ultimate overload | 300% R.C |
