Indicator
LDS67870 LDS29980
-High brightness LED(height 57mm)
-RS-232C, RS-422, Current Loop
- PDF：LDS67870 LDS29980
- INQUIRY
Series LDS67870
-High brightness LED(height 57mm)
-RS-232C, RS-422, Current Loop
-Wall mounting type
-Uniform brightness and wide angle viewing
SPECIFICATIONS
TYPE | LDS67870 |
Display | High brightness 2.3-inch 7-segment numeric LED display |
Digit Digit | 6 Digits |
Size of digit | 56.9 mm High |
LED color | Red |
Interface | RS-232C, RS-422, Current loop |
Operating temp. | -10~60℃ |
Power supply | AC110/220V，IPH 50/60 Hz or DC 12V |
Power consumption | Appr.2VA |
Series LDS29980
- High brightness LED(height 100mm)
-RS-232C, RS-422, Current Loop
-Wall mounting type
-Uniform brightness and wide angle viewing
SPECIFICATIONS
TYPE | LDS29980 |
Display | High brightness 4-inch 7-segment numeric LED display |
Digit Digit | 5 Digits |
Size of digit | 100 mm |
LED color | Red |
Interface | RS-232C, RS-422, Current loop |
Operating temp. | -10~60℃ |
Power supply | AC110~240V，IPH 50/60 Hz or DC 12V |
Power consumption | Appr.3VA |
* Specifications are subiect to change without notice
