MTCK10

Rated capacity (R.C.)

10,20,30kg

50,100kg

Material

Alunminum

Stainless Steel

Rated output(R.O.)

2.0mV/V ±10%

Non-linearity

≤0.05% R.O.

Hysteresis

≤0.03% R.O.

Non-repeatability

≤0.03% R.O.

Creep error

≤0.05% in 20min.

Zero balance

≤1% R.O.

Compensated temperature range

-10~70℃

Operating temperature range

-20~80℃

Temp, effect on rated output

≤0.03% LOAD/10℃

Temp, effect on zero balance

≤0.03% R.O./10℃

Terminal input resistance

420 ±20 Ohms

420 ±20 Ohms

Terminal output resistance

350 ±5 Ohms

350 ±5 Ohms

Insulation resistance (Min.)

2000 MOhms at 50V DC

Excitation voltage

5V(Recommended),10V(Max.)

Electrial connection

ø3mmx1.5m(28AWGx4Core Shielded)

Protection class

Meets IP64

Safe overload

150% R.C

Ultimate overload

300% R.C
