Tension Loadcell
UPBL
Series UPBL
Under Pillow Block Load Cells
UPBL's-Series are used in conjunction with pillow block mounted, bearings and a shaft to create a durable and precise tension roll that's easy to install.With an IP67 rating the UPBL-Series offers an extreme level of protection and performance for applications in wet, dusty, chemical,corrosive or other harsh environments.
Features
-Enhanced reliability simplifi es tension control protection and repeatability
- Full Semiconductor Wheatstone Bridge
- Built-in overload stops
-Chemical and corrosion resistant
-High overload protection protects workers, equipment and product
-Drilled and tapped to customer bearing specifi catio
SPECIFICATIONS
Supply voltag | 5V DC | Load Rating*- lb(N)
25………….….20(100)/50 (250）/110(500)/225(1000) 25………….….110(500)/280(1250) /560(2500)/1120(5000) | |
Output | 250mV,nominal@full load | ||
Deflection (at nominal force) | 0.005to0.010（0.3to0.25）typ. 0.010（0.3to0.25）typ. | ||
Non-Linearity & hysteresis (combined) | ±0.5% full span | Operating temp. °F(° c) | -4 to +185(-20 to +85) |
Overload stops | Factory set @ 110% | Non-Repeata bility | ±0.02% full span |
Enclosure protection class | IP 67 | ||
* Specifications are subject to change without notice
